R01UH0823EJ0100 Rev.1.00 Page 131 of 1823
Jul 31, 2019
RX23W Group 5. I/O Registers
000A 8496h RSCAN Receive Buffer Register 15BH RMPTR15 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8498h RSCAN Receive Buffer Register 15CL RMDF015 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 849Ah RSCAN Receive Buffer Register 15CH RMDF115 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 849Ch RSCAN Receive Buffer Register 15DL RMDF215 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 849Eh RSCAN Receive Buffer Register 15DH RMDF315 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8580h
to
000A 859Fh
RSCAN RAM Test Register 0 to RAM Test Register 15 RPGACC0 to
RPGACC15
16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85A0h RSCAN Receive FIFO Access Register 0AL RFIDL0 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85A0h RSCAN RAM Test Register 16 RPGACC16 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85A2h RSCAN Receive FIFO Access Register 0AH RFIDH0 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85A2h RSCAN RAM Test Register 17 RPGACC17 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85A4h RSCAN Receive FIFO Access Register 0BL RFTS0 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85A4h RSCAN RAM Test Register 18 RPGACC18 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85A6h RSCAN Receive FIFO Access Register 0BH RFPTR0 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85A6h RSCAN RAM Test Register 19 RPGACC19 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85A8h RSCAN Receive FIFO Access Register 0CL RFDF00 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85A8h RSCAN RAM Test Register 20 RPGACC20 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85AAh RSCAN Receive FIFO Access Register 0CH RFDF10 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85AAh RSCAN RAM Test Register 21 RPGACC21 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85ACh RSCAN Receive FIFO Access Register 0DL RFDF20 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85ACh RSCAN RAM Test Register 22 RPGACC22 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85AEh RSCAN Receive FIFO Access Register 0DH RFDF30 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85AEh RSCAN RAM Test Register 23 RPGACC23 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85B0h RSCAN Receive FIFO Access Register 1AL RFIDL1 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85B0h RSCAN RAM Test Register 24 RPGACC24 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85B2h RSCAN Receive FIFO Access Register 1AH RFIDH1 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85B2h RSCAN RAM Test Register 25 RPGACC25 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85B4h RSCAN Receive FIFO Access Register 1BL RFTS1 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85B4h RSCAN RAM Test Register 26 RPGACC26 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85B6h RSCAN Receive FIFO Access Register 1BH RFPTR1 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85B6h RSCAN RAM Test Register 27 RPGACC27 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85B8h RSCAN Receive FIFO Access Register 1CL RFDF01 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85B8h RSCAN RAM Test Register 28 RPGACC28 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85BAh RSCAN Receive FIFO Access Register 1CH RFDF11 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85BAh RSCAN RAM Test Register 29 RPGACC29 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85BCh RSCAN Receive FIFO Access Register 1DL RFDF21 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85BCh RSCAN RAM Test Register 30 RPGACC30 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85BEh RSCAN Receive FIFO Access Register 1DH RFDF31 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85BEh RSCAN RAM Test Register 31 RPGACC31 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85C0h
to
000A 85DEh
RSCAN RAM Test Register 32 to RAM Test Register 47 RPGACC32 to
RPGACC47
16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85E0h RSCAN0 Transmit/Receive FIFO Access Register 0AL CFIDL0 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85E0h RSCAN RAM Test Register 48 RPGACC48 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85E2h RSCAN0 Transmit/Receive FIFO Access Register 0AH CFIDH0 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85E2h RSCAN RAM Test Register 49 RPGACC49 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85E4h RSCAN0 Transmit/Receive FIFO Access Register 0BL CFTS0 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85E4h RSCAN RAM Test Register 50 RPGACC50 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85E6h RSCAN0 Transmit/Receive FIFO Access Register 0BH CFPTR0 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85E6h RSCAN RAM Test Register 51 RPGACC51 16 16 2 or 3 PCLKB 2 IC
LK section 36.
000
A 85E8h RSCAN0 Transmit/Receive FIFO Access Register 0CL CFDF00 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85E8h RSCAN RAM Test Register 52 RPGACC52 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 85EAh RSCAN0 Transmit/Receive FIFO Access Register 0CH CFDF10 16 16 2 or 3 PCLKB 2 ICLK section 36.
Table 5.1 List of I/O Registers (Address Order) (27/31)
