RX23W Group 44. 12-Bit A/D Converter (S12ADE)
Table 44.2 Functions of 12-Bit A/D Converter
Note 1. See section 11, Low Power Consumption for details.
Item
Pin Name,
Abbreviation
Analog input channels AN000 to AN007,
AN016 to AN020,
AN027,
temperature
sensor output,
internal reference
voltage
Conditions for
A/D conversion
start
Software Software trigger Enabled
Asynchronous
trigger
ADTRG0# Enabled
Synchronous
trigger
Compare match/input capture from MTU0.TGRA TRG0AN
Compare match/input capture from MTU0.TGRB TRG0BN
Compare match/input capture from MTU0 to MTU4.TGRA or underflow
(trough) of MTU4.TCNT in complementary PWM mode
TRGAN
Compare match from MTU0.TGRE TRG0EN
Compare match from MTU0.TGRF TRG0FN
Compare match between MTU4.TADCORA and MTU4.TCNT (interrupt
skipping function)
TRG4AN
Compare match between MTU4.TADCORB and MTU4.TCNT (interrupt
skipping function)
TRG4BN
Compare match between MTU4.TADCORA and MTU4.TCNT or compare
match between MTU4.TADCORB and MTU4.TCNT (interrupt skipping
function)
TRG4ABN
TGRA compare match/input capture from TPU0 to TPU4 or TGRA compare
match/input capture from TPU0
TRGAN1
TRG4ABN1
ELC trigger Enabled
Interrupt S12ADI0, GBADI
interrupt
Setting of the module stop function*
1
MSTPCRA.
MSTPA17 bit
