Renesas RX Series User Manual

R01UH0823EJ0100 Rev.1.00 Page 1552 of 1823
Jul 31, 2019
RX23W Group 44. 12-Bit A/D Converter (S12ADE)
Table 44.7 lists the selection of A/D conversion start sources selected by the TRSA[5:0] bits.
Table 44.6 Selection of A/D Activation Sources by the TRSB[5:0] Bits
Table 44.7 Selection of A/D Activation Sources by the TRSA[5:0] Bits
Module Source Remarks TRSB[5] TRSB[4] TRSB[3] TRSB[2] TRSB[1] TRSB[0]
Trigger source deselection state 1 1 1 1 1 1
MTU TRG0AN Compare match/input capture from MTU0.TGRA 0 0 0 0 0 1
TRG0BN Compare match/input capture from MTU0.TGRB 0 0 0 0 1 0
TRGAN Compare match/input capture from MTU0 to
MTU4.TGRA or underflow (trough) of MTU4.TCNT in
complementary PWM mode
000011
TRG0EN Compare match from MTU0.TGRE 0 0 0 1 0 0
TRG0FN Compare match from MTU0.TGRF 0 0 0 1 0 1
TRG4AN Compare match between MTU4.TADCORA and
MTU4.TCNT (interrupt skipping function)
000110
TRG4BN Compare match between MTU4.TADCORB and
MTU4.TCNT (interrupt skipping function)
000111
TRG4ABN Compare match between MTU4.TADCORA and
MTU4.TCNT or compare match between
MTU4.TADCORB and MTU4.TCNT (interrupt skipping
function)
001000
TPU TRGAN1 TGRA compare match/input capture from TPU0 to
TPU4
001101
TRG4ABN1 TGRA compare match/input capture from TPU0 0 0 1 1 1 0
ELC ELCTRG0 001001
Module Source Remarks TRSA[5] TRSA[4] TRSA[3] TRSA[2] TRSA[1] TRSA[0]
Trigger source deselection state 1 1 1 1 1 1
External pin ADTRG0# Input pin for the trigger 0 0 0 0 0 0
MTU TRG0AN Compare match/input capture from MTU0.TGRA 0 0 0 0 0 1
TRG0BN Compare match/input capture from MTU0.TGRB 0 0 0 0 1 0
TRGAN Compare match/input capture from MTU0 to
MTU4.TGRA or underflow (trough) of MTU4.TCNT in
complementary PWM mode
000011
TRG0EN Compare match from MTU0.TGRE 0 0 0 1 0 0
TRG0FN Compare match from MTU0.TGRF 0 0 0 1 0 1
TRG4AN Compare match between MTU4.TADCORA and
MTU4.TCNT (interrupt skipping function)
000110
TRG4BN Compare match between MTU4.TADCORB and
MTU4.TCNT (interrupt skipping function)
000111
TRG4ABN Compare match between MTU4.TADCORA and
MTU4.TCNT or compare match between
MTU4.TADCORB and MTU4.TCNT (interrupt skipping
function)
001000
TPU TRGAN1 TGRA compare match/input capture from TPU0 to
TPU4
001101
TRG4ABN1 TGRA compare match/input capture from TPU0 0 0 1 1 1 0
ELC ELCTRG0 001001
