R01UH0823EJ0100 Rev.1.00 Page 413 of 1823
Jul 31, 2019
RX23W Group 20. Event Link Controller (ELC)
Table 20.3
Correspondence between Values Set in ELSRn.ELS[7:0] Bits and Event Signals (1/2)
ELS[7:0] Bit Value Peripheral Modules Event Signal Set in ELSRn
08h Multifunction timer pulse unit 2 MTU1 compare match 1A
09h MTU1 compare match 1B
0Ah MTU1 overflow
0Bh MTU1 underflow
0Ch MTU2 compare match 2A
0Dh MTU2 compare match 2B
0Eh MTU2 overflow
0Fh MTU2 underflow
10h MTU3 compare match 3A
11h MTU3 compare match 3B
12h MTU3 compare match 3C
13h MTU3 compare match 3D
14h MTU3 overflow
15h MTU4 compare match 4A
16h MTU4 compare match 4B
17h MTU4 compare match 4C
18h MTU4 compare match 4D
19h MTU4 overflow
1Ah MTU4 underflow
1Fh Compare match timer CMT1 compare match 1
22h 8-bit timers TMR0 compare match A0
23h TMR0 compare match B0
24h TMR0 overflow
28h TMR2 compare match A2
29h TMR2 compare match B2
2Ah TMR2 overflow
2Eh Realtime clock RTC periodic event
(select 1/256, 1/128, 1/64, 1/32, 1/16, 1/8, 1/4, 1/2, 1, or 2 seconds)
31h Independent watchdog timer IWDT underflow or refresh error
32h Low power timer LPT compare match
34h 12-bit A/D converter S12AD comparison conditions are met
35h S12AD comparison conditions are not met
3Ah Serial communications interfaces SCI5 error (receive error or error signal detection)
3Bh SCI5 receive data full
3Ch SCI5 transmit data empty
3Dh SCI5 transmit end
4Eh I
2
C bus interface RIIC0 communication error or event generation
4Fh RIIC0 receive data full
50h RIIC0 transmit data empty
51h RIIC0 transmit end
52h Serial peripheral interface RSPI0 error (mode fault, overrun, or parity error)
53h RSPI0 idle
54h RSPI0 receive data full
55h RSPI0 transmit data empty
56h RSPI0 transmit end
To Next Page
