R01UH0823EJ0100 Rev.1.00 Page 440 of 1823

Jul 31, 2019

RX23W Group 21. I/O Ports

Figure 21.9 I/O Port Configuration (9)

Port E: PE0 to PE4

Peripheral module output signal

Reading the port

PMR

PDR

PODR

Enable peripheral module output

Input signal of peripheral module/

interrupt

PCR

1: ON

0: OFF

ISEL bit

ASEL bit

ODR0, ODR1

Analog input

Note 1. Control signal for N-channel open-drain output (other than PE1)

Control signal for N-channel open-drain and P-channel open-drain (PE1)

Note 2. An external interrupt function is multiplexed on this pin

Internal bus
