RX23W Group 22. Multi-Function Pin Controller (MPC)

Note 1. Select general input (by setting the Bm bits for the given pin in the PDR and PMR for the given port to 0) for the pin if this pin

function is to be used.

Comparator B CMPB2 (input)*

P15 

CVREFB2 (input)*

P14 

CMPB3 (input)*

P26 

CVREFB3 (input)*

P27 

CMPOB2 (output) P17 

CMPOB3 (output) P30 

Capacitive touch sensing unit (CTSU) TSCAP (output) PC4 

TS2 (output) P27 

TS3 (output) P26 

TS4 (output) P25  ×

TS7 (output) P22

 ×

TS8 (output) P21

 ×

TS12 (output) P15



TS13 (output) P14 

TS22 (output) PC6 

TS23 (output) PC5 

TS27 (output) PC3 

TS30 (output) PC2 

TS35 (output) PC0 

Table 22.1 Allocation of Pin Functions to Multiple Pins (6/6)
