R01UH0823EJ0100 Rev.1.00 Page 556 of 1823

Jul 31, 2019

RX23W Group 23. Multi-Function Timer Pulse Unit 2 (MTU2a)

Figure 23.41 Example of Operation without Dead Time

MTU3.TGRA

= TCDR + 1

TCDR

0000h

Buffer register

MTU4.TGRC

Temporary register

Compare register

MTU4.TGRA

Positive-phase output Initial output

Initial output

Negative-phase output

Output waveform is active-low

Data 1 Data 2

Transfer from temporary

MTU4.TGRA

MTU4.TGRC

TDDR = 1

MTU3.TCNT

MTU4.TCNT

TCNTS
