RX23W Group 25. 16-Bit Timer Pulse Unit (TPUa)
Note: This setting is invalid when TPU1 is in phase counting mode.
Note: This setting is invalid when TPU2 is in phase counting mode.
Table 25.4 Bits TPSC[2:0] (TPU0)
Channel
Bits TPSC[2:0]
Descriptionb2 b1 b0
TPU0 0 0 0 Internal clock: counts on PCLK/1
0 0 1 Internal clock: counts on PCLK/4
0 1 0 Internal clock: counts on PCLK/16
0 1 1 Internal clock: counts on PCLK/64
1 0 0 External clock: counts on TCLKA pin input
1 0 1 External clock: counts on TCLKB pin input
1 1 0 External clock: counts on TCLKC pin input
1 1 1 External clock: counts on TCLKD pin input
Table 25.5 Bits TPSC[2:0] (TPU1)
Channel
Bits TPSC[2:0]
Descriptionb2 b1 b0
TPU1 0 0 0 Internal clock: counts on PCLK/1
0 0 1 Internal clock: counts on PCLK/4
0 1 0 Internal clock: counts on PCLK/16
0 1 1 Internal clock: counts on PCLK/64
1 0 0 External clock: counts on TCLKA pin input
1 0 1 External clock: counts on TCLKB pin input
1 1 0 Internal clock: counts on PCLK/256
1 1 1 Counts on TPU2.TCNT overflow/underflow
Table 25.6 Bits TPSC[2:0] (TPU2)
Channel
Bits TPSC[2:0]
Descriptionb2 b1 b0
TPU2 0 0 0 Internal clock: counts on PCLK/1
0 0 1 Internal clock: counts on PCLK/4
0 1 0 Internal clock: counts on PCLK/16
0 1 1 Internal clock: counts on PCLK/64
1 0 0 External clock: counts on TCLKA pin input
1 0 1 External clock: counts on TCLKB pin input
1 1 0 External clock: counts on TCLKC pin input
1 1 1 Internal clock: counts on PCLK/1024
