R01UH0823EJ0100 Rev.1.00 Page 672 of 1823

Jul 31, 2019

RX23W Group 25. 16-Bit Timer Pulse Unit (TPUa)

x: Don’t care

Table 25.18 TPU5.TIOR

Bits IOB[3:0] Description

b7 b6 b5 b4 TPU5.TGRB Function TIOCB5 Pin Function and Related Issue

0000Output compare register Output disabled

0001 Initial output is low output; low output at compare match

0010 Initial output is low output; high output at compare match

0011 Initial output is low output; toggle output at compare match

0100 Output disabled

0101 Initial output is high output; low output at compare match

0110 Initial output is high output; high output at compare match

0111 Initial output is high output; toggle output at compare match

1 x 0 0 Input capture register Capture input source is TIOCB5 input capture at rising edge

1 x 0 1 Capture input source is TIOCB5 input capture at falling edge

1 x 1 x Capture input source is TIOCB5 input capture at both edges
