R01UH0823EJ0100 Rev.1.00 Page 730 of 1823

Jul 31, 2019

RX23W Group 26. 8-Bit Timer (TMR)

Table 26.3 lists the I/O pins of the TMR.

Table 26.3 Pin Configuration of TMR

Unit Channel Pin Name I/O Description

0 TMR0 TMO0 Output Outputs compare match

TMCI0 Input Inputs external count clock

TMR1 TMO1 Output Outputs compare match

TMCI1 Input Inputs external count clock

TMRI1 Input Inputs external counter reset

1 TMR2 TMO2 Output Outputs compare match

TMCI2 Input Inputs external count clock

TMRI2 Input Inputs external counter reset

TMR3 TMCI3 Input Inputs external count clock

TMRI3 Input Inputs external counter reset
