RX23W Group 32. USB 2.0 Host/Function Module (USBc)

Figure 32.2 Sample OTG Connection of USB Connector in Self-Powered State

External connection

MCU

USB0_EXICEN

USB0_VBUSEN

USB0_OVRCURA

USB0_OVRCURB

USB0_ID

SHDN#

OFFVBUS#

STATUS1

STATUS2

ID_OUT

ID_IN

VBUS

USB0_DP

USB

AB connector

D+

D–

VBUS

USB transceiver

OTG power

supply IC

USB0_DM

DRV

: Output impedance

: Pull-up resistor

: Pull-down resistor

DRV
