RX23W Group 33. Serial Communications Interface (SCIg, SCIh)

Figure 33.3 Block Diagram of SCIh (SCI12)

Transmit/

receive

block

Extended serial mode control

section

Controller

Timer

RXI interrupt request

TXI interrupt request

TEI interrupt request

ERI interrupt request

SCIX0 interrupt request

SCIX1 interrupt request

SCIX2 interrupt request

SCIX3 interrupt request

RXD12/SSCL12/

SMISO12/RXDX12

TXD12/SSDA12/

SMOSI12/TXDX12/

SIOX12

RTS12#/CTS12#/SS12#

SCK12

Internal peripheral bus

TMO0

TMO1

TMR
