Keysight x-series Instruction Manual

3 Short-Range Comms & IoT Mode
3.8 SEM Measurement
When the max number of offsets is 14 in these modes, the preset value of Offset G ~ N is the same as
the Offset F value
WLAN Mode: See the table of "WLAN Mode Presets" on page 1127 below
When the max number of offsets is 6:
Mode Values
SA
ON, OFF, ON, ON, ON, ON
WCDMA
ON, OFF, ON, ON, ON, ON | ON, ON, ON, ON, ON, ON
LTE, LTETDD
OFF, ON, ON, ON, ON, ON | ON, ON, ON, ON, ON, ON
When the max number of offsets is 12 in these modes, the preset value of Offset G ~ L is the same as
the Offset F value
Mode Values
LTEAFDD,
LTEATDD, 5G
NR
OFF, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON | ON, ON,
ON, ON, ON, ON, ON, ON, ON, ON, ON, ON
MSR
ON, OFF, OFF, OFF, ON, OFF, OFF, OFF, OFF, OFF, OFF, OFF |
ON, OFF, OFF, OFF, ON, OFF, OFF, OFF, OFF, OFF, OFF, OFF
When the max number of offsets is 14 in these modes, the preset value of Offset G ~ N is the same as
the Offset F value
WLAN Mode: See the table of "WLAN Mode Auto Function Presets" on page 1128 below
State Saved Saved in instrument state
Saved in instrument state
Range Auto|Man
Min/Max -200 dBm/50 dBm
WLAN Mode Presets
Radio Std Presets
802.11b/g (DSSS/CCK/PBCC) -4.00 dBm, -12.00 dBm, -24.00 dBm, -24.00 dBm, -24.00 dBm, -
24.00 dBm, -24.00 dBm, -24.00 dBm, -24.00 dBm, -24.00 dBm, -
24.00 dBm, -24.00 dBm, -24.00 dBm, -24.00 dBm
802.11a/g (OFDM/DSSS-
OFDM)
-10 dBm, -30 dBm, -30 dBm, -30 dBm, -30 dBm, -30 dBm, -30
dBm, -30 dBm, -30 dBm, -30 dBm, -30 dBm, -30 dBm, -30 dBm,
-30 dBm
802.11n/ac/ax/be (20MHz) -4.00 dBm, -12.00 dBm, -24.00 dBm, -63.00 dBm, -63.00 dBm, -
63.00 dBm, -63.00 dBm, -63.00 dBm, -63.00 dBm, -63.00 dBm, -
63.00 dBm, -63.00 dBm, -63.00 dBm, -63.00 dBm
802.11n/ac/ax/be (40MHz) -4.00 dBm, -12.00 dBm, -24.00 dBm, -66.00 dBm, -66.00 dBm, -
66.00 dBm, -66.00 dBm, -66.00 dBm, -66.00 dBm, -66.00 dBm, -
66.00 dBm, -66.00 dBm, -66.00 dBm, -66.00 dBm
Short Range Comms & IoT Mode User's &Programmer's Reference 1127
