3 Short-Range Comms & IoT Mode
3.8 SEM Measurement
the Offset F value
Mode Values
LTEAFDD,
LTEATDD, 5G
NR, MSR
0 dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB|0 dB, 0
dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB
When the max number of offsets is 14 in these modes, the preset value of Offset G ~ N is the same as
the Offset F value
WLAN Mode: See table of "WLAN Mode Presets" on page 1132 below
When the max number of offsets is 6:
Mode Values
SA
ON, ON, ON, ON, ON, ON
WCDMA
ON, ON, ON, ON, ON, ON | OFF, OFF, OFF, ON, ON, ON
When the max number of offsets is 12 in these modes, the preset value of Offset G ~ L is the same as
the Offset F value
Mode Values
LTEAFDD,
LTEATDD, 5G NR,
MSR
ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON | ON, ON,
ON, ON, ON, ON, ON, ON, ON, ON, ON, ON
When the max number of offsets is 14 in these modes, the preset value of Offset G ~ N is the same as
the Offset F value
WLAN Mode: See table of "WLAN Mode Auto Function Presets" on page 1133 below
State Saved Saved in instrument state
Saved in instrument state
Range Auto|Man
Min/Max -200 dB/50 dB
WLAN Mode Presets
Radio Std Presets
802.11a/g
(OFDM/DSSS-OFDM)
-20.00 dB, -28.00 dB, -40.00 dB, -40.00 dB, -47.00 dB, -47.00 dB, -
47.00 dB, -47.00 dB, -47.00 dB, -47.00 dB, -47.00 dB, -47.00 dB, -47.00
dB, -47.00 dB
802.11b/g
(DSSS/CCK/PBCC)
-30 dB, -50 dB, -50 dB, -50 dB, -50 dB, -50 dB, -50 dB, -50 dB, -50 dB, -
50 dB, -50 dB, -50 dB, -50 dB, -50 dB
802.11n
(20MHz/40MHz)
-20.00 dB, -28.00 dB, -45.00 dB, -45.00 dB, -45.00 dB, -45.00 dB, -
45.00 dB, -45.00 dB, -45.00 dB, -45.00 dB, -45.00 dB, -45.00 dB, -45.00
dB, -45.00 dB
802.11ac/ax/be (20 -20.00 dB, -28.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -
1132 Short Range Comms & IoT Mode User's &Programmer's Reference
