3 Short-Range Comms & IoT Mode
3.9 Occupied BW Measurement
Note that, since out-of-range Start Freq and Stop Freq are never allowed, markers and trace math
work correctly without requiring any special handling for out-of-range conditions
Preset Depends on instrument maximum frequency, mode, measurement, and selected input
See "Center Frequency Presets" on page 1280 and "Ext Mix Center Freq" on page 1283
State Saved Saved in instrument state
Min/Max Depends on instrument maximum frequency, mode, measurement, and selected input
See "Center Frequency Presets" on page 1280 and "Ext Mix Center Freq" on page 1283
Annotation Center <value> appears in the lower left corner of the display
Status Bits/OPC
dependencies
Non-overlapped
Center Frequency Presets
The following table provides the Center Frequency Presets for the Spectrum
Analyzer mode, and the Max Freq, for the various frequency options:
Freq Option CF after Mode
Preset
Stop Freq after Mode
Preset
Max Freq
(can't tune
above)
503 (all but CXA) 1.805 GHz 3.6 GHz 3.7 GHz
503 (CXA) 1.505 GHz 3.0 GHz 3.08 GHz
507 (all but CXA) 3.505 GHz 7.0GHz 7.1 GHz
507 (CXA) 3.755 GHz 7.5GHz 7.58 GHz
508 (all but MXE) 1.805 GHz 3.6GHz 8.5 GHz
508 (MXE) 4.205 GHz 8.4GHz 8.5 GHz
513 6.805 GHz 13.6GHz 13.8 GHz
526 (except CXA and
MXE)
13.255 GHz 26.5 GHz 27.0 GHz*
526 (CXA) 13.255 GHz 26.5GHz 26.55 GHz
526 (MXE) 1.805 GHz 3.6GHz 27.0 GHz
532 16.005 GHz 32.0GHz 32.5 GHz
540 20.005 GHz 40.0GHz 40.5GHz
543 21.505 GHz 43.0 GHz 43.0 GHz
544 22.005 GHz 44.0 GHz 45.0 GHz
550 25.005 GHz 50.0 GHz 52 GHz
F03 (CXA-m) 1.505 GHz 3.0 GHz 3.08 GHz
F07 (CXA-m) 3.755 GHz 7.5GHz 7.575 GHz
F13 (CXA-m) 6.805 GHz 13.6GHz 13.8 GHz
F26 (CXA-m) 13.255 GHz 26.5GHz 26.55 GHz
1280 Short Range Comms & IoT Mode User's &Programmer's Reference
