3 Short-Range Comms & IoT Mode
3.12 Monitor Spectrum Measurement
[:SENSe]:MONitor:BANDwidth:VIDeo:RATio:AUTO OFF | ON | 0 | 1
[:SENSe]:MONitor:BANDwidth:VIDeo:RATio:AUTO?
Example
:MON:BAND:VID:RAT 2
:MON:BAND:VID:RAT?
:MON:BAND:VID:RAT:AUTO 0
:MON:BAND:VID:RAT:AUTO?
Notes The values shown in this table reflect the conditions after a Mode Preset
Couplings See "Coupling Auto Rules" on page 1677
Preset 1
ON
State Saved Saved in instrument state
Min 0.00001
Max 3000000
Backwards
Compatibility
Notes
For backwards compatibility this command accepts both the BANDwidth and BWIDth forms
Coupling Auto Rules
The Auto Rules for the VBW:3dB RBW function are as follows.
First, if Source Mode is set to “Tracking”: Use 1.0
Otherwise, we go through the following list of detector numbers and find the lowest
numbered detector being used on any active traces (traces for which Update is On):
1.
Peak
2.
Normal
3.
Average
4.
Sample
5.
Negative Peak
6.
EMI Average
7.
Quasi Peak
8.
RMS Average
Use that detector to pick the ratio based on the following criteria:
Short Range Comms & IoT Mode User's &Programmer's Reference 1677
