Keysight x-series Instruction Manual

3 Short-Range Comms & IoT Mode
3.12 Monitor Spectrum Measurement
Center Frequency, Center Frequency Offset and Carrier Reference Frequency are coupled. When
Carrier Reference Frequency changes:
–
Center Frequency : Auto Center Frequency = Carrier Reference Frequency + Center Frequency
Offset (fixed)
–
Center Frequency : Man Center Frequency (fixed) = Carrier Reference Frequency + Center
Frequency Offset
Preset
ON
State Saved Saved in instrument state
Range
Auto|Man
Center Frequency Presets
The following table provides the Center Frequency Presets for the Spectrum
Analyzer mode, and the Max Freq, for the various frequency options:
Freq Option CF after Mode
Preset
Stop Freq after Mode
Preset
Max Freq
(can't tune
above)
503 (all but CXA) 1.805 GHz 3.6 GHz 3.7 GHz
503 (CXA) 1.505 GHz 3.0 GHz 3.08 GHz
507 (all but CXA) 3.505 GHz 7.0GHz 7.1 GHz
507 (CXA) 3.755 GHz 7.5GHz 7.58 GHz
508 (all but MXE) 1.805 GHz 3.6GHz 8.5 GHz
508 (MXE) 4.205 GHz 8.4GHz 8.5 GHz
513 6.805 GHz 13.6GHz 13.8 GHz
526 (except CXA and
MXE)
13.255 GHz 26.5 GHz 27.0 GHz*
526 (CXA) 13.255 GHz 26.5GHz 26.55 GHz
526 (MXE) 1.805 GHz 3.6GHz 27.0 GHz
532 16.005 GHz 32.0GHz 32.5 GHz
540 20.005 GHz 40.0GHz 40.5GHz
543 21.505 GHz 43.0 GHz 43.0 GHz
544 22.005 GHz 44.0 GHz 45.0 GHz
550 25.005 GHz 50.0 GHz 52 GHz
F03 (CXA-m) 1.505 GHz 3.0 GHz 3.08 GHz
F07 (CXA-m) 3.755 GHz 7.5GHz 7.575 GHz
F13 (CXA-m) 6.805 GHz 13.6GHz 13.8 GHz
F26 (CXA-m) 13.255 GHz 26.5GHz 26.55 GHz
504 (M9421A, M8920A) 2.145 GHz 3.88GHz 3.88 GHz
1690 Short Range Comms & IoT Mode User's &Programmer's Reference

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
