6 Input/Output
6.1 RF Source
numeric keypad displays the unit terminator.
Remote
Command
:SOURce:FREQuency[:CW] <freq>
:SOURce:FREQuency[:CW]?
Example
:SOUR:FREQ 1.00 GHz
Notes Internal source has list sequence mode, which comprises of several steps that contain separate output
power, frequency and waveform etc. When the source list sequence playing is complete, the last step
keeps playing, and you can use this command to change the list sequence last step’s output frequency
Couplings The frequency value is coupled to the current channel band and number, such that updates to the band
and number will update the frequency value to the corresponding absolute frequency
Preset
E7760B Depends on port selected
EXM, with license F1A or 5WC 2.412GHz
VXT Models with Radio
Heads/CIU
See "VXT Models with Remote Radio Heads/CIU" on page
1958
M941xE(VXT Models with
M9471A)
See "M941xE(VXT Models with M9471A)" on page 1958
All other models 1.00 GHz
Min
E7760B Depends on port selected
VXT model M9420A 60 MHz
VXT models
M9410A/11A/15A/16A
380 MHz
VXT model M9411A with Option
LFE
1 MHz
VXT Models with Radio
Heads/CIU
See "VXT Models with Remote Radio Heads/CIU" on page
1958
M941xE(VXT Models with
M9471A)
See "M941xE(VXT Models with M9471A)" on page 1958
All other models 10.00 MHz
Max Hardware Dependent:
Option 503 3.6 GHz
Option 504 3.8 GHz
Option 506 6.00 GHz
Option F06 6.00 GHz
Parameters for "VXT models M9415A/16A" on page 1958
Parameters for "VXT Models with Remote Radio Heads/CIU" on page 1958
Parameters for "M941xE(VXT Models with M9471A)" on page 1958
For E7760B: Depends on port selected
For EXM, if license 5WC is present, the frequency range should be limited to: 1.1GHz-1.7GHz, 2.4GHz-
2.5GHz, 4.8GHz-6.0GHz. If the user-defined frequency is outside of range, reports error message
“Settings conflict; Frequency is outside available range”
1957 Short Range Comms & IoT Mode User's &Programmer's Reference
