6 Input/Output
6.1 RF Source
VXT models M9410A/11A
RF Output Port Preset Min Without Option
“LFE”
Min With Option
“LFE”
Max
RF Output 1 GHz 380 MHz 1 MHz 6 GHz
RFHD 1 GHz 380 MHz 1 MHz 6 GHz
VXT models M9415A/16A
Freq Option Preset Min Max
F06 1 GHz 380 MHz 6.0 GHz
F08 1 GHz 380 MHz 8.0 GHz
F12 1 GHz 380 MHz 12.3 GHz
E7760B
RF Output Port Preset Min Max
IFIO 16 GHz 2 GHz 18 GHz
M1650A 58.32 GHz 55 GHz 69 GHz
M1720A 28 GHz 25 GHz 29 GHz
VXT Models with Remote Radio Heads/CIU
Products with Radio Heads/CIU Preset Min frequency Max frequency
VXT + CIU 6 GHz 5.9 GHz 12 GHz
VXT + CIU + RRH 28GHz 24.25GHz 43.5GHz
VXT + M1742A RRH 28 GHz 10 GHz 32 GHz
M941xE(VXT Models with M9471A)
Products with M9471A Preset Minimum
settable
frequency
Minimum
frequency
with Spec
Maximum
settable
frequency
M941xE without LFE option 1 GHz 330 MHz 380MHz 26.5GHz
M941xE with LFE option
(LFE option in M9411A or
M9471A)
1 GHz 750 kHz 1MHz 26.5GHz
NOTE
The minimum spec frequency is 380 MHz, minimum settable center frequency is
330 MHz.
With Option LFE in M9411A or in M9471A, the minimum settable frequency is
750 kHz, but Spec to customer only ensure down to 1 MHz.
Short Range Comms & IoT Mode User's &Programmer's Reference 1958

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
