6 Input/Output

6.1 RF Source

Min E7760B: 2.64 GHz

All Others: 1.00 kHz

Max Hardware Dependent:

E7760B 2.64 GHz

VXT model M9420A Option B40 50 MHz

Option B85 100 MHz

Option B1X 200 MHz

VXT models M9410A/11A and M9410E/11E Option B40 50 MHz

Option B3X 375 MHz

Option B6X 750 MHz

Option B12 1.5 GHz

VXT models M9415A/16A and M9415E/16E Option B4X 500 MHz

Option B8X 1.0 GHz

Option B12 1.5 GHz

For VXT models M9410A/11A/15A/16A, M9410E/11E/15E/16E and E6680A/81A, the sample rate is

only limited by the option, but the IF BW is limited by center frequency in addition to options. See

"More Information" on page 1980. Performance is guaranteed only when the bandwidth of the

selected waveform is smaller than the Max IF BW

More Information

Although the range of Sample Rate only depends on the installed option, the

Maximum IF BW depends on options as well as the Center Frequency.

VXT models M9410A/11A, E6680A and E6681A

Option Limitation:

Option Maximum IF BW

B40 40 MHz

B3X 300 MHz

B6X 600 MHz

B12 1200 MHz

Center Frequency Limitation:

Center Frequency Maximum IF BW

6.5 kHz ~ 9 kHz (Option LFE) (CF – 6.5 kHz) * 2

9 kHz ~ 100 kHz (Option LFE) 5 kHz

Short Range Comms & IoT Mode User's &Programmer's Reference 1980
