6 Input/Output

6.1 RF Source

Example

:SOUR:RAD:ARB:TRIG:EXT:DEL 100ns

:SOUR:RAD:ARB:TRIG:EXT:DEL?

Notes External trigger delay time set by users will be rounded to the nearest integer multiple of the

resolution

Dependencies Unavailable and grayed-out when Trigger Source is not set to EXTernal1 or EXTernal2

Not available in E7760B

Preset 1 ms

Min VXT models M9410A/11A/15A/16A and M9410E/11E/15E/16E: -10 s

All others: 0s

Max

Instrument/Condition Value Derivation

VXT models M9410A/11A/15A/16A 11.45324612 s 2.666667ns *(2^32-1)

M9410E/11E/15E/16E 11.45324612 s 2.666667ns *(2^32-1)

Continuous – Trigger + Run 11.45324612 s 2.666667ns *(2^32-1)

Other trigger conditions 17.17986918 s 4 ns *(2^32-1)

All others 8.589934588 s 4ns * (2^31 – 1) = 8589934588 ns

Auto Function

Remote

Command

:SOURce:RADio:ARB:TRIGger[:SOURce]:EXTernal:DELay:STATe OFF | ON | 0 | 1

:SOURce:RADio:ARB:TRIGger[:SOURce]:EXTernal:DELay:STATe?

Example

:SOUR:RAD:ARB:TRIG:EXT:DEL:STAT ON

:SOUR:RAD:ARB:TRIG:EXT:DEL:STAT?

Preset

OFF

More Information

There is a time interval (system processing time) between the trigger event and the

beginning of playing waveform. The figure below shows you the behavior. The

negative trigger delay allows you to specify the beginning of a waveform.
