7 Save/Recall/Print
7.3 Save
My Documents\<mode name>\state
where <mode name> is the parameter used to select the mode with :INST:SEL (for
example, BASIC for IQ Analyzer Mode).
NOTE
In products that run multiple simultaneous instances of the X-Series Application,
all instances share the same registers and file directories, so take care not to
overwrite files and/or registers from one instance that were saved by another
instance.
Trace+State files have the extension .trace. The default filename is State_
0000.trace, where the 4-digit number is the lowest number that does not conflict
with any filename in the current directory.
The Trace+State selection only appears for measurements that support trace saves.
It is blanked for modes that do not support trace saves. Saving Trace is identical to
saving State except a .trace extension is used on the file instead of .state, and
internal flags are set in the file indicating which trace was saved.
See "More Information" on page 2262.
Remote
Command
:MMEMory:STORe:TRACe TRACE1 | TRACE2 | TRACE3 | TRACE4 | TRACE5 | TRACE6 |
ALL,<filename>
:MMEMory:STORe:TRACe:REGister TRACE1 | TRACE2 | TRACE3 | TRACE4 | TRACE5 |
TRACE6 | ALL,<integer>
Example Save the file myState.trace on the default path and flags it as a “single trace” file with Trace 1 as
the single trace (even though all of the traces are in fact stored):
:MMEM:STOR:TRAC TRACE1,"myState.trace"
Save the file myState.trace on the default path and flags it as an “all traces” file:
:MMEM:STOR:TRAC ALL,"myState.trace"
Store trace 1 data in trace register 2:
:MMEM:STOR:TRAC:REG TRACE1,2
Notes This command actually performs a Save State, which in the Swept SA measurement includes the trace
data. However, it flags it (in the file) as a “save trace” file of the specified trace (or all traces)
Some Modes and measurements do not have available all 6 traces. The Phase Noise Mode command,
for example, is:
:MMEMory:STORe:TRACe TRACE1 | TRACE2 | TRACE3 | ALL,<filename>
Some modes and measurements have more than 6 traces available. The Realtime SA Mode command,
for example, is:
:MMEMory:STORe:TRACe TRACE1 | TRACE2 | TRACE3 | TRACE4 | TRACE5 | TRACE6 |
TRACE7 | TRACE8 | TRACE9 | TRACE10 | TRACE11 | TRACE12 | ALL,<filename>
The range for the register parameter is 1-5
When you initiate a save, if the file already exists, a dialog will appear that allows you to replace the
existing file by selecting OK or you can cancel the request. If you select OK, the file will be overwritten.
Using the C: drive is strongly discouraged, since it runs the risk of being overwritten during an
instrument software upgrade
Short Range Comms & IoT Mode User's &Programmer's Reference 2261
