3 Short-Range Comms & IoT Mode
3.4 HRP UWB Demodulation Measurement
n Return Value
The Q values are the odd-indexed values.
Not specified
or 1
Returns the following comma-separated scalar results:
# Item Unit
1 Frequency Error Hz
2 Channel Power dBm
3 Time Offset s
4 Rmarker – first chip after SFD s
5 Chip Clock Error ppm
6 Main Lobe Peak
7 Main Lobe Width s
8 Side Lobe Peak
9 Side Lobe Peak Position s
10 Data Average Power dBm
11 Data Peak Power dBm
12 SHR Averaged Power dBm
13 SHR Peak Power dBm
14 STS Averaged Power dBm
15 STS Peak Power dBm
16 SHR Normalized RMSE %
17 Data Normalized RMSE %
18 STS Normalized RMSE %
19 Overall Normalized RMSE %
20 Transmit PSD Mask
21 Impulse Response Mask
22 Pulse Shape Monotonically Increase
23 PHR Normalized RMSE %
24 PDSU Normalized RMSE %
25 SHR Avg Pulse Amplitude dB
26 PHR Avg Pulse Amplitude dB
27 PSDU Avg Pulse Amplitude dB
28 STS Avg Pulse Amplitude dB
29 Symbol Clock Jitter s
2 Returns the following comma-separated Pass/Fail results:
1 Pass/Fail result of Frequency Error
2 Pass/Fail result of Chip Clock Error
Short Range Comms & IoT Mode User's &Programmer's Reference 433
