3 Short-Range Comms & IoT Mode
3.7 ACP Measurement
n Results Returned
781
4 Returns <Num Pts> comma-separated scalar values representing the Y values in Trace 1
5 Returns <Num Pts> comma-separated scalar values representing the Y values in Trace 2
6 Returns <Num Pts> comma-separated scalar values representing the Y values in Trace 3
7 Dependent on Mode and "Measurement Type" on page 947. See "Measurement Results for n = 7" on page
781
8 Only available in LTEAFDD, LTEATDD, 5GNR, MSR Modes
Dependent on "Measurement Type" on page 947, "PSD Unit" on page 955, and "Power Ref" on page 948.
See "Measurement Results for n = 8" on page 782
9 Only available in LTEAFDD, LTEATDD, 5GNR, MSR Modes
Returns scalar pass/fail values (0 = passed, or 1 = failed) for the trace specified by "Measure Trace" on
page 1508, determined by comparing the relative to the reference carrier and by testing the absolute
power limit of the offset frequencies
# Item
1 Inner Lower offset A - relative limit result
2 Inner Lower offset A - absolute limit result
3 Inner Upper offset A - relative limit result
4 Inner Upper offset A - absolute limit result
5 Inner Lower offset B - relative limit result
6 Inner Lower offset B - absolute limit result
7 Inner Upper offset B - relative limit result
8 Inner Upper offset B - absolute limit result
… ...
When "Max Num of Offsets" on page 902 is 6, returns 24 results (Offset A-F: 24 = 4*6) and when set to 12,
returns 48 results (Offset A-L: 48 = 4 * 12)
10 Only available in LTEAFDD, LTEATDD, 5GNR, MSR Modes
Returns scalar values of offset results for the trace specified by "Measure Trace" on page 1508
Numbers returned in this trace are 10 x the actual measured offsets. Note that upper and lower sides of an
offset are returned separately. For example, when only outer offset A is measured with offset side both, 10 x
2 = 20 values are returned
In the table below, f is the Number of Offsets. See "Max Num of Offsets" on page 902
# Measurement Type Item Unit, if any
1 Inner = 1 or Outer = 2
2 Offset A~L. (A = 1, B = 2, ... L = 12)
3 Offset Side. Lower = 1 or Upper = 2
774 Short Range Comms & IoT Mode User's &Programmer's Reference
