3 Short-Range Comms & IoT Mode
3.7 ACP Measurement
Enabled or Disabled. When the Number of Component Carrier within each sub-
block = 1, sub-block (bandwidth) = BW
channel
= 2 x F
offset,RAT
.
See "Diagrams for Offset Freq Define" on page 914.
Modes other than MSR, LTEAFDD, LTEATDD, 5G NR
Remote
Command
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:TYPE CTOCenter | CTOEdge | ETOCenter |
ETOEdge
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:TYPE?
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
Example
:ACP:OFFS:TYPE ETOC
:ACP:OFFS:TYPE?
Notes Some Modes do not support Offset subopcode 2. In those cases, commands with subopcode 2 are
accepted without error but ignored
Preset
CTOCenter
State Saved Saved in instrument state
Range
CTOCenter|CTOEdge|ETOCenter|ETOEdge
Mode: MSR, LTEAFDD, LTEATDD
Remote
Command
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:TYPE CTOCenter | CTOEdge | ETOCenter |
ETOEdge
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:TYPE?
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
Example
:ACP:OFFS:TYPE ETOC
:ACP:OFFS:TYPE?
Preset
CTOCenter
State Saved Saved in instrument state
Range
CTOCenter|CTOEdge|ETOCenter|ETOEdge
Mode: 5G NR
Remote
Command
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:TYPE CTOCenter | CTOEdge | ETOCenter |
ETOEdge | RTOCenter | RTOEdge | RCTOCenter | SCTOCenter
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:TYPE?
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
Example
:ACP:OFFS:TYPE ETOC
Short Range Comms & IoT Mode User's &Programmer's Reference 913
