R01UH0823EJ0100 Rev.1.00 Page 1475 of 1823

Jul 31, 2019

RX23W Group 41. Bluetooth Low Energy (BLE)

Table 41.3 lists the Bluetooth Low Energy functions that this MCU supports. The use of these functions requires the

Bluetooth middleware.

Table 41.3 List of Supported Bluetooth Low Energy Functions

Function Bluetooth

core spec

Low Energy Controller (PHY and LL) v4.0

Low Energy Host (L2CAP and Security Manager)

Attribute Protocol and Generic Attribute Profile

Appearance Data Type v4.1

Low Duty Cycle Directed Advertising

32-bit UUID Support in LE

LE L2CAP Connection Oriented Channel Support

LE Link Layer Topology

LE Ping

LE Data Packet Length Extension v4.2

LE Secure Connections

Link Layer Privacy

Link Layer Extended Filter Policies

LE 2M PHY v5.0

LE Coded PHY

High Duty Cycle Non-Connectable Advertising

LE Advertising Extensions

LE Channel Selection Algorithm #2
