RX23W Group 51. Electrical Characteristics
Table 51.12 DC Characteristics (10)
Conditions: VCC = VCC_USB = AVCC0 = VCC_RF = AVCC_RF = 3.3 V, VSS = AVSS0 = VSS_USB = VSS_RF = 0 V,
T
a
= +25°C
Item Symbol
Typ.
Unit Test ConditionsTransmit output power
0 dBm 4 dBm
BLE operating current
(when the DC-to-DC converter is
selected)
Idd_tx 4.3 8.7 mA Transmit mode, 2Mbps
Transmit mode, 1Mbps
4.5 8.7 Transmit mode, 500kbps
Transmit mode, 125kbps
Idd_rx 3.0 3.5 mA Receive mode, 2Mbps
Prf = –67dBm
3.0 3.4 Receive mode, 1Mbps
Prf = –67dBm
3.2 3.5 Receive mode, 500kbps
Prf = –72dBm
3.3 3.5 Receive mode, 125kbps
Prf = –79dBm
Idd_idle 0.5 mA Idle mode
Idd_slp 1.5 µA Deep sleep mode
Idd_down 0.1 µA Power down mode
BLE operating current
(when the linear regulator is selected)
Idd_tx 10.2 18.1 mA Transmit mode, 2Mbps
Transmit mode, 1Mbps
Transmit mode, 500kbps
Transmit mode, 125kbps
Idd_rx 6.9 mA Receive mode, 2Mbps
Prf = –67dBm
6.9 Receive mode, 1Mbps
Prf = –67dBm
6.9 Receive mode, 500kbps
Prf = –72dBm
7.1 Receive mode, 125kbps
Prf = –79dBm
Idd_idle 0.7 mA Idle mode
Idd_slp 1.5 µA Deep sleep mode
Idd_down 0.1 µA Power down mode
Table 51.13 DC Characteristics (11)
Conditions: 1.8 V ≤ VCC = VCC_USB = AVCC0 = VCC_RF = AVCC_RF ≤ 3.6 V, VSS = AVSS0 = VSS_USB = VSS_RF = 0 V,
T
a
= –40 to +85°C
Item Symbol Min. Typ. Max. Unit Test Conditions
RAM standby voltage V
RAM
1.8 — — V
