R01UH0823EJ0100 Rev.1.00 Page 359 of 1823

Jul 31, 2019

RX23W Group 18. DMA Controller (DMACA)

Figure 18.3 Operation in Repeat Transfer Mode

DMSAR

Transfer source data area

(Specified as a repeat area)

DMDAR

Transfer

Transfer destination data area

Data 1

Data 2

Data 3

Data 4

Data 1

Data 2

Data 3

Data 4

Data 1

Data 2

Data 3

Data 4
