R01UH0823EJ0100 Rev.1.00 Page 435 of 1823

Jul 31, 2019

RX23W Group 21. I/O Ports

Figure 21.4 I/O Port Configuration (4)

Port 3: P30, P31

Peripheral module output signal

Reading the port

PMR

ODR0, ODR1

PDR

PODR

Enable peripheral module output

Input signal of peripheral module/interrupt

PCR

ISEL bit

1: ON

0: OFF

RTC time capture event input signal

Reading the port

NMI input signal

Port 3: P35

Note 1. Control signal for N-channel open-drain output.

Internal busInternal bus
