Renesas RX Series User Manual

R01UH0823EJ0100 Rev.1.00 Page 660 of 1823
Jul 31, 2019
RX23W Group 25. 16-Bit Timer Pulse Unit (TPUa)
Table 25.3 lists the input/output pins of the TPU.
Table 25.3 Pin Configuration of TPU
Channel Pin Name I/O Description
Common TCLKA Input External clock A input pin (TPU1 and TPU5 phase counting mode A phase input)
TCLKB Input External clock B input pin (TPU1 and TPU5 phase counting mode B phase input)
TCLKC Input External clock C input pin (TPU2 and TPU4 phase counting mode A phase input)
TCLKD Input External clock D input pin (TPU2 and TPU4 phase counting mode B phase input)
TPU0 TIOCB0 I/O TPU0.TGRB input capture input/output compare output/PWM output pin
TPU1 TIOCB1 I/O TPU1.TGRB input capture input/output compare output/PWM output pin
TPU2 TIOCB2 I/O TPU2.TGRB input capture input/output compare output/PWM output pin
TPU3 TIOCA3 I/O TPU3.TGRA input capture input/output compare output/PWM output pin
TIOCB3 I/O TPU3.TGRB input capture input/output compare output/PWM output pin
TIOCC3 I/O TPU3.TGRC input capture input/output compare output/PWM output pin
TIOCD3 I/O TPU3.TGRD input capture input/output compare output/PWM output pin
TPU4 TIOCA4 I/O TPU4.TGRA input capture input/output compare output/PWM output pin
TIOCB4 I/O TPU4.TGRB input capture input/output compare output/PWM output pin
TPU5 TIOCB5 I/O TPU5.TGRB input capture input/output compare output/PWM output pin
