R01UH0823EJ0100 Rev.1.00 Page 713 of 1823

Jul 31, 2019

RX23W Group 25. 16-Bit Timer Pulse Unit (TPUa)

(5) Buffer Operation Timing

Figure 25.37 and Figure 25.38 show the timings in buffer operation.

Figure 25.37 Buffer Operation Timing (Compare Match)

Figure 25.38 Buffer Operation Timing (Input Capture)

Compare match signal

TGRA, TGRB

TCNT

PCLK

TGRC, TGRD

N + 1n

Input capture signal

TGRA, TGRB

TCNT

PCLK

TGRC, TGRD

NN + 1

NN + 1n
