RX23W Group 25. 16-Bit Timer Pulse Unit (TPUa)

(4) Timing for Counter Clearing by Compare Match/Input Capture

Figure 25.35 shows the timing when counter clearing by compare match occurrence is specified, and Figure 25.36

shows the timing when counter clearing by input capture occurrence is specified.

Figure 25.35 Counter Clear Timing (Compare Match)

Figure 25.36 Counter Clear Timing (Input Capture)

0000h

Compare match signal

Counter clear signal

TPUm.TCNT

TPUm.TGRy

PCLK

0000hN

Input capture signal

Counter clear signal

TPUm.TCNT

TPUm.TGRy

PCLK
