R01UH0823EJ0100 Rev.1.00 Page 994 of 1823

Jul 31, 2019

RX23W Group 33. Serial Communications Interface (SCIg, SCIh)

Table 33.20 BRR Settings for Various Bit Rates (Smart Card Interface Mode, n = 0, S = 372)

Bit Rate (bps) PCLK (MHz) n N Error (%)

9600 7.1424 0 0 0.00

10.00 0 1 –30.00

10.7136 0 1 –25.00

13.00 0 1 –8.99

14.2848 0 1 0.00

16.00 0 1 12.01

18.00 0 2 –15.99

20.00 0 2 –6.66

25.00 0 3 –12.49

30.00 0 3 5.01

Table 33.21 Maximum Bit Rate for Each Operating Frequency (Smart Card Interface Mode, S = 32)

PCLK (MHz) Maximum Bit Rate (bps) n N

10.00 156250 0 0

10.7136 167400 0 0

13.00 203125 0 0

16.00 250000 0 0

18.00 281250 0 0

20.00 312500 0 0

25.00 390625 0 0

30.00 468750 0 0
