Direct Memory Access (DMA)
4.3.4.8 DMA_USEBURSTCLR Register (offset = 1Ch) [reset = 0h]
DMA_USEBURSTCLR is shown in Figure 4-14 and described in Table 4-18.
Each bit of this register represents the corresponding DMA channel. Setting a bit clears the corresponding
SET[n] bit in the DMAUSEBURSTSET register.
Figure 4-14. DMA_USEBURSTCLR Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
CLR_n
W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 4-18. DMA_USEBURSTCLR Register Field Descriptions
Bit Field Type Reset Description
31-0 CLR_n W 0h
Channel [n] Useburst Clear
0h = No Effect
1h = Setting a bit clears the corresponding SET[n] bit in the
DMAUSEBURSTSET register meaning that DMA channel [n]
responds to single and burst requests
