15.6.20 GPIO3CLKEN Register (offset = 68h) [reset = 0h]
GPIO3CLKEN is shown in Figure 15-23 and described in Table 15-23.
Figure 15-23. GPIO3CLKEN Register
31 30 29 28 27 26 25 24
RESERVED
R-0h
23 22 21 20 19 18 17 16
RESERVED DSLPCLKEN
R-0h R/W-0h
15 14 13 12 11 10 9 8
NU1 SLPCLKEN
R-0h R/W-0h
7 6 5 4 3 2 1 0
NU2 RUNCLKEN
R-0h R/W-0h
Table 15-23. GPIO3CLKEN Register Field Descriptions
Bit Field Type Reset Description
31-17 RESERVED R 0h
16 DSLPCLKEN R/W 0h
GPIO_D_DSLP_CLK_ENABLE
0h = Disable GPIO_D clock during deep-sleep mode
1h = Enable GPIO_D clock during deep-sleep mode
15-9 NU1 R 0h
8 SLPCLKEN R/W 0h
GPIO_D_SLP_CLK_ENABLE
0h = Disable GPIO_D clock during sleep mode
1h = Enable GPIO_D clock during sleep mode
7-1 NU2 R 0h
0 RUNCLKEN R/W 0h
GPIO_D_RUN_CLK_ENABLE
0h = Disable GPIO_D clock during run mode
1h = Enable GPIO_D clock during run mode
