SD Host Controller Interface
11.7 SD-HOST Registers
Table 11-4 lists the memory-mapped registers for the SD-HOST. All register offset addresses not listed in
Table 11-4 should be considered as reserved locations and the register contents should not be modified.
Table 11-3. Base Address of SD-Host (also referred as MMCHS)
Module Name Base Address
MMCHS1 0x4401 0000
Table 11-4. SD-HOST Registers
Offset Acronym Register Name Section
124h MMCHS_CSRE Card Status Response Error Section 11.7.1
12Ch MMCHS_CON Configuration Section 11.7.2
204h MMCHS_BLK Transfer Length Configuration Section 11.7.3
208h MMCHS_ARG Command Argument Section 11.7.4
20Ch MMCHS_CMD Command and Transfer Mode Section 11.7.5
210h MMCHS_RSP10 Command Response[31:0] Section 11.7.6
214h MMCHS_RSP32 Command Response[63:32] Section 11.7.7
218h MMCHS_RSP54 Command Response[95:64] Section 11.7.8
21Ch MMCHS_RSP76 Command Response[127:96] Section 11.7.9
220h MMCHS_DATA Data Section 11.7.10
224h MMCHS_PSTATE Present State Section 11.7.11
228h MMCHS_HCTL Control Section 11.7.12
22Ch MMCHS_SYSCTL SD System Control Section 11.7.13
230h MMCHS_STAT Interrupt Status Section 11.7.14
234h MMCHS_IE Interrupt SD Enable Section 11.7.15
238h MMCHS_ISE Interrupt Signal Enable Section 11.7.16
