Power, Reset, and Clock Management
15.6.19 GPIO2SWRST Register (offset = 64h) [reset = 0h]
GPIO2SWRST is shown in Figure 15-22 and described in Table 15-22.
Figure 15-22. GPIO2SWRST Register
31 30 29 28 27 26 25 24
RESERVED
R-0h
23 22 21 20 19 18 17 16
RESERVED
R-0h
15 14 13 12 11 10 9 8
RESERVED
R-0h
7 6 5 4 3 2 1 0
RESERVED ENSTS SWRST
R-0h R-0h R/W-0h
Table 15-22. GPIO2SWRST Register Field Descriptions
Bit Field Type Reset Description
31-2 RESERVED R 0h
1 ENSTS R 0h
GPIO_C_ENABLED_STATUS
0h = GPIO_C clocks and resets are disabled
1h = GPIO_C clocks and resets are enabled
0 SWRST R/W 0h
GPIO_C_SOFT_RESET
0h = Deassert reset for GPIO_C
1h = Assert reset for GPIO_C
