SHA/MD5 Functional Description
www.ti.com
700
SWRU543–January 2019
Submit Documentation Feedback
Copyright © 2019, Texas Instruments Incorporated
SHA/MD5 Accelerator
If the three passes are not performed in succession, the digest registers must be saved and restored for
the next use of the SHA/MD5 engine. If the rounds are performed consecutively, there is no need to do
anything with the digest registers.
Table 19-6. SHA Digest Processed in One Pass
Digest (A to E) SHAMD5_DIGEST_CO
UNT
SHAMD5_MODE and
SHAMD5_LENGTH
SHAMD5_DATA_n_IN
First pass WRITE:
LENGTH=129
ALGO (dependent on
the algorithm to apply)
ALGO_CONSTANT=1
CLOSE_HASH=1
First 64 bytes of
message
Round 1 digest
calculation
Second 64 bytes of
message
Round 2 digest
calculation
Last byte of message
Final digest Read: 129
19.1.3.2 MD5 Mode
19.1.3.2.1 Starting a New Hash
To start a new hash, perform the following steps:
1. Set the ALGO bit field in the SHAMD5_MODE register to 0x0 to select the MD5 algorithm.
2. Set the ALGO_CONSTANT bit to 1 in the SHAMD5_MODE register to initialize all digest registers from
SHAMD5_ODIGEST_A/SHAMD5_IDIGEST_A to SHAMD5_ODIGEST_H/SHAMD5_IDIGEST_H with
default values specified by the algorithm, and set the SHAMD5_DIGESTCOUNT register to 0.
3. Specify the LENGTH field in the SHAMD5_LENGTH register of the hash data to process in bytes.
4. Set the CLOSE_HASH bit in the SHAMD5_MODE register to let the SHA/MD5 engine do the padding.
If MD5 is computed in one shot, the length of the message can be any value up to ? what?. To
process an intermediate MD5 digest, the CLOSE_HASH bit is set to 0, in which case packets to be
hashed must be 64 bytes; the last packet must be hashed with the CLOSE_HASH bit set to 1.
After the configuration is complete, the hash engine can receive the data to process (the INPUT_READY
bit is 1 in the SHAMD5_IRQSTATUS register). Data must be written to the 16 × 32-bit
SHAMD5_DATA_n_IN registers that provide storage for one 64-byte block of data. Unless the
CLOSE_HASH bit is set in the SHAMD5_MODE register, the SHAMD5_DATA_n_IN 64-byte input buffer
must be filled. Data can be written by single write transactions to the 16 registers from a processor or by a
µDMA transfer.
For a µDMA transfer, the SDAM_EN bit must be set in the SHAMD5_SYSCONFIG register before starting
the new hash and the µDMA channel for SHA/MD5 0 data in request must be configured. The µDMA must
be configured to the appropriate hash transfer size. A µDMA done is asserted after the last
SHAMD5_DATA_n_IN register is filled.
The module detects that a 64-byte block is available, and then moves the data to a working register space
for processing and sets the INPUT_READY bit to 1 in the SHAMD5_IRQSTATUS register. If the
PDMA_EN bit is set in the SHAMD5_SYSCONFIG register, then a new µDMA request triggers a new
block transfer; otherwise, the processor polls the INPUT_READY bit in the SHAMD5_IRQSTATUS register
and writes the 16 data words of 32 bits when it equals 1.
This operation repeats until the length of the message to hash is reached. The OUTPUT_READY bit in the
SHAMD5_IRQSTATUS register then indicates that the hash operation is complete. If the PIT_EN bit in the
SHAMD5_SYSCONFIG register is set, an interrupt (active low) is also generated to indicate the hash
completion.
