Advance Encryption Standard Accelerator (AES)
17.4.27 AES_DATA_IN_2 Register (Offset = 68h) [reset = 0h]
AES_DATA_IN_2 is shown in Figure 17-40 and described in Table 17-30.
Return to Summary Table.
Data register to read and write plaintext and ciphertext.
Figure 17-40. AES_DATA_IN_2 Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
DATA
R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 17-30. AES_DATA_IN_2 Register Field Descriptions
Bit Field Type Reset Description
31-0 DATA R/W 0h
Data to encrypt or decrypt
17.4.28 AES_DATA_IN_3 Register (Offset = 6Ch) [reset = 0h]
AES_DATA_IN_3 is shown in Figure 17-41 and described in Table 17-31.
Return to Summary Table.
Data register to read and write plaintext and ciphertext (LSW).
Figure 17-41. AES_DATA_IN_3 Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
DATA
R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 17-31. AES_DATA_IN_3 Register Field Descriptions
Bit Field Type Reset Description
31-0 DATA R/W 0h
Data to encrypt or decrypt
