Inter-Integrated Sound (I2S) Multichannel Audio Serial Port
12.5.28 XBUFn Register (Offset = 200h) [reset = 0h]
XBUFn is shown in Figure 12-31 and described in Table 12-33.
Return to Summary Table.
The transmit buffers for the serializers (XBUF) hold data from the transmit format unit.
CAUTION
Accessing XBUF registers that are not implemented on a specific DSP may
cause improper device operation.
Figure 12-31. XBUFn Registers
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
XBUFn
R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 12-33. XBUFn Register Field Descriptions
Bit Field Type Reset Description
31-0 XBUFn R/W 0h
For transmit operations, the XBUF is an alias of the XRBUF in the
serializer. The XBUF can be accessed through the peripheral
configuration port (see ) or through the DMA port (see ).
