Analog-to-Digital Converter (ADC)
13.4.1.20 ADC_CH6_FIFO_LVL Register (offset = ACh) [reset = 0h]
ADC_CH6_FIFO_LVL is shown in Figure 13-22 and described in Table 13-22.
Figure 13-22. ADC_CH6_FIFO_LVL Register
31 30 29 28 27 26 25 24
RESERVED
R-0h
23 22 21 20 19 18 17 16
RESERVED
R-0h
15 14 13 12 11 10 9 8
RESERVED
R-0h
7 6 5 4 3 2 1 0
RESERVED ADC_CHANNEL6_FIFO_LVL
R-0h R-0h
Table 13-22. ADC_CH6_FIFO_LVL Register Field Descriptions
Bit Field Type Reset Description
31-3 RESERVED R 0h
2-0 ADC_CHANNEL6_FIFO_
LVL
R 0h
This register shows the current FIFO level. FIFO is 4 words wide.
Possible supported levels are 0x0 to 0x4.
