Watchdog Timer
10.3.2 WDTVALUE Register (offset = 4h) [reset = FFFFFFFFh]
WDTVALUE is shown in Figure 10-3 and described in Table 10-3.
This register contains the current count value of the timer.
Figure 10-3. WDTVALUE Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
WDTVALUE
R-FFFFFFFFh
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 10-3. WDTVALUE Register Field Descriptions
Bit Field Type Reset Description
31-0 WDTVALUE R FFFFFFFFh Watchdog Value Current value of the 32-bit down counter
