15.6.17 GPIO1SWRST Register (offset = 5Ch) [reset = 0h]
GPIO1SWRST is shown in Figure 15-20 and described in Table 15-20.
Figure 15-20. GPIO1SWRST Register
31 30 29 28 27 26 25 24
RESERVED
R-0h
23 22 21 20 19 18 17 16
RESERVED
R-0h
15 14 13 12 11 10 9 8
RESERVED
R-0h
7 6 5 4 3 2 1 0
RESERVED ENSTS SWRST
R-0h R-0h R/W-0h
Table 15-20. GPIO1SWRST Register Field Descriptions
Bit Field Type Reset Description
31-2 RESERVED R 0h
1 ENSTS R 0h
GPIO_B_ENABLED_STATUS
0h = GPIO_B clocks and resets are disabled
1h = GPIO_B clocks and resets are enabled
0 SWRST R/W 0h
GPIO_B_SOFT_RESET
0h = Deassert reset for GPIO_B
1h = Assert reset for GPIO_B
