User Application
Image linked to
address 0x0100_0800
Image SHA pattern 20 Bytes
Auto appended by
ImageCreator tool
Application code
Initial Stack Pointer (SP)
Reset Vector (PC)
Programming, Bootstrapping, and Updating the Flash User Application
www.ti.com
780
SWRU543–January 2019
Submit Documentation Feedback
Copyright © 2019, Texas Instruments Incorporated
On-Chip Parallel Flash
21.8 Programming, Bootstrapping, and Updating the Flash User Application
Direct programming of the on-chip flash using JTAG or flash-loaders is not supported by the CC3235SF
device. During programming, the image is always first downloaded onto the serial flash, using the filename
/sys/mcuflashimg.bin. During the first-time boot, the bootloader reads the encrypted image from serial
flash, decrypts it, and writes it onto the on-chip flash. The bootloader ensures that the on-chip flash image
is always in sync with that on the serial flash. Otherwise, if a valid image is detected on the on-chip flash,
the bootloader will pass on the execution control to that image.
The user application image binary should be linked to run from 0x0100_0800.
Figure 21-12 shows the final structure of the image on the serial flash, where the initial 20-byte SHA-1
hash is auto-computed by the image creator and appended to the image provided by the user.
Transferring the image from the serial flash to the on-chip flash is a multistep process. The process starts
by detecting the /sys/mcuflashimg.bin file on the serial flash. When the file is detected, the whole image is
transferred to on-chip flash, skipping the first 20 bytes. A SHA-1 hash for the transferred portion is
computed and verified against the SHA-1 at offset 0 on the serial flash file. Finally, the header is written
onto the on-chip flash offset 0, to identify the image as valid.
The first 20-byte hash part of the serial flash file /sys/mcuflashimg.bin is not copied nor does it take part in
the generation of SHA-1 by the bootloader. The first 20-byte hash serves as an identifier for detecting a
new image on serial flash. A mismatch with the previously stored hash triggers an update cycle, and the
transfer process is repeated.
Figure 21-12. User Application Image Binary Structure on Serial Flash
