I/O Pads and Pin Multiplexing
16.8.1 Pad Configuration Registers for Application Pins
Table 16-11 lists the configuration registers associated with the device pins.
(1)
Pins are referred either by number or by the GPIO mapped to that pin. Functionalities available on a pin are not limited to that
name. Refer to the pin-mux table for all possible functional mapping.
(2)
These four pins are dedicated for the external SPI serial flash. These cannot be used or shared in any way for other functions.
Table 16-11. Pad Configuration Registers
Package Pin Number GPIO Number
(1)
Digital Pad
Configuration Register
Physical Address
50 GPIO0 / (ANA) GPIO_PAD_CONFIG_0 0x4402 E0A0
55 GPIO1 GPIO_PAD_CONFIG_1 0x4402 E0A4
57 GPIO2 GPIO_PAD_CONFIG_2 0x4402 E0A8
58 GPIO3 GPIO_PAD_CONFIG_3 0x4402 E0AC
59 GPIO4 GPIO_PAD_CONFIG_4 0x4402 E0B0
60 GPIO5 GPIO_PAD_CONFIG_5 0x4402 E0B4
61 GPIO6 GPIO_PAD_CONFIG_6 0x4402 E0B8
62 GPIO7 GPIO_PAD_CONFIG_7 0x4402 E0BC
63 GPIO8 GPIO_PAD_CONFIG_8 0x4402 E0C0
64 GPIO9 GPIO_PAD_CONFIG_9 0x4402 E0C4
1 GPIO10 GPIO_PAD_CONFIG_10 0x4402 E0C8
2 GPIO11 GPIO_PAD_CONFIG_11 0x4402 E0CC
3 GPIO12 GPIO_PAD_CONFIG_12 0x4402 E0D0
4 GPIO13 GPIO_PAD_CONFIG_13 0x4402 E0D4
5 GPIO14 GPIO_PAD_CONFIG_14 0x4402 E0D8
6 GPIO15 GPIO_PAD_CONFIG_15 0x4402 E0DC
7 GPIO16 GPIO_PAD_CONFIG_16 0x4402 E0E0
8 GPIO17 GPIO_PAD_CONFIG_17 0x4402 E0E4
11 GPIO18 (SPI_FLASH_CLK)
(2)
GPIO_PAD_CONFIG_18 0x4402 E0E8
12 GPIO19 (SPI_FLASH_DOUT
(2)
GPIO_PAD_CONFIG_19 0x4402 E0EC
13 GPIO20 (SPI_FLASH_DIN)
(2)
GPIO_PAD_CONFIG_20 0x4402 E0F0
14 GPIO21 (SPI_FLASH_CS)
(2)
GPIO_PAD_CONFIG_21 0x4402 E0F4
15 GPIO22 GPIO_PAD_CONFIG_22 0x4402 E0F8
16 GPIO23 (TDI) GPIO_PAD_CONFIG_23 0x4402 E0FC
17 GPIO24 (TDO) GPIO_PAD_CONFIG_24 0x4402 E100
18 GPIO28 GPIO_PAD_CONFIG_40 0x4402 E140
19 GPIO28 (TCK) GPIO_PAD_CONFIG_28 0x4402 E110
21 GPIO25 (SOP2) GPIO_PAD_CONFIG_25 0x4402 E104
29 GPIO26 (ANTSEL1) GPIO_PAD_CONFIG_26 0x4402 E108
30 GPIO27 (ANTSEL2) GPIO_PAD_CONFIG_27 0x4402 E10C
20 GPIO29 (TMS) GPIO_PAD_CONFIG_29 0x4402 E114
53 GPIO30 (ANA) GPIO_PAD_CONFIG_30 0x4402 E118
45 GPIO31 (DCDC_ANA2_SW_P) GPIO_PAD_CONFIG_31 0x4402 E11C
52 GPIO32 (RTC_XTAL_N) GPIO_PAD_CONFIG_32 0x4402 E120
