Inter-Integrated Sound (I2S) Multichannel Audio Serial Port
12.5.22 XTDM Register (Offset = B8h) [reset = 0h]
XTDM is shown in Figure 12-25 and described in Table 12-27.
Return to Summary Table.
The transmit TDM time slot register (XTDM) specifies in which TDM time slot the transmitter is active.
TDM time slot counter range is extended to 384 slots (to support SPDIF blocks of 384 subframes). XTDM
operates modulo 32, that is, XTDMS specifies the TDM activity for time slots 0, 32, 64, 96, 128, and so
forth.
Figure 12-25. XTDM Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
XTDMS[31-0]
R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 12-27. XTDM Register Field Descriptions
Bit Field Type Reset Description
31-0 XTDMS[31-0] R/W 0h
Transmitter mode during TDM time slot n.
0h = Transmit TDM time slot n is inactive. The transmit serializer
does not shift out data during this slot.
1h = Transmit TDM time slot n is active. The transmit serializer shifts
out data during this slot according to the serializer control register
(SRCTL).
