SPI Registers
www.ti.com
294
SWRU543–January 2019
Submit Documentation Feedback
Copyright © 2019, Texas Instruments Incorporated
SPI (Serial Peripheral Interface)
Table 8-9. SPI_IRQSTATUS Register Field Descriptions (continued)
Bit Field Type Reset Description
1 TX_UNDERFLOW R/W 0h
Transmitter register underflow.
0h (W) = Event status bit unchanged
0h (R) = Event false
1h (W) = Event status bit is reset
1h (R) = Event is pending
0 TX_EMPTY R/W 0h Transmitter register empty or almost empty.
This bit indicate FIFO almost full status when built-in FIFO is use for
transmit register (SPI_CHCONF[FFEW] is set).
0h (W) = Event status bit unchanged
0h (R) = Event false
1h (W) = Event status bit is reset
1h (R) = Event is pending
