581
SWRU543–January 2019
Submit Documentation Feedback
Copyright © 2019, Texas Instruments Incorporated
I/O Pads and Pin Multiplexing
Chapter 16
SWRU543–January 2019
I/O Pads and Pin Multiplexing
Topic ........................................................................................................................... Page
16.1 Overview ......................................................................................................... 582
16.2 I/O Pad Electrical Specifications......................................................................... 583
16.3 Analog and Digital Pin Multiplexing .................................................................... 584
16.4 Special Analog/Digital Pins................................................................................ 584
16.5 Analog Mux Control Registers ........................................................................... 587
16.6 Pins Available for Applications .......................................................................... 589
16.7 Functional Pin Mux Configurations..................................................................... 591
16.8 Pin Mapping Recommendations......................................................................... 603
