I/O Pads and Pin Multiplexing
Table 16-6. GPIO/Pins Available for Application (continued)
Package Pin Name
Pins That Can be Used by Application Using 40-MHz Crystal
Yes = 1
Pins That Can be Used by Application Using 40-MHz TCXO
(For Full Industrial Temperature Range)
Yes = 1
4-Wire JTAG
SOP[2:0] = 000
with 32-kHz
Crystal
2-Wire JTAG
SOP[2:0] = 001
with 32-kHz
Crystal
4-Wire JTAG
SOP[2:0] = 000
with External
32 kHz Crystal
2-Wire JTAG
SOP[2:0] = 001
with External
32 kHz Crystal
4-Wire JTAG
SOP[2:0] = 000
with 32-kHz
Crystal
2-Wire JTAG
SOP[2:0] = 001
with 32-kHz
Crystal
4-Wire JTAG
SOP[2:0] = 000
with External
32-kHz Crystal
2-Wire JTAG
SOP[2:0] = 001
with External
32-kHz Crystal
56 VDD_DIG2
57 GPIO2 1 1 1 1 1 1 1 1
58 GPIO3 1 1 1 1 1 1 1 1
59 GPIO4 1 1 1 1 1 1 1 1
60 GPIO5 1 1 1 1 1 1 1 1
61 GPIO6 1 1 1 1 1 1 1 1
62 GPIO7 1 1 1 1 1 1 1 1
63 GPIO8 1 1 1 1 1 1 1 1
64 GPIO9 1 1 1 1 1 1 1 1
65
GND (THERMAL
PAD)
Total available for application 22 24 23 25 22 24 23 25
16.7 Functional Pin Mux Configurations
Pin mux configurations supported in the CC32xx are listed in Table 16-7.
