15.6.1 CAMCLKCFG Register (offset = 0h) [reset = 0h]
CAMCLKCFG is shown in Figure 15-4 and described in Table 15-4.
Figure 15-4. CAMCLKCFG Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RESERVED
R-0h
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RESERVED DIVOFFTIM NU1 DIVONTIM
R-0h R/W-0h R-0h R/W-0h
Table 15-4. CAMCLKCFG Register Field Descriptions
Bit Field Type Reset Description
31-11 RESERVED R 0h
10-8 DIVOFFTIM R/W 0h
CAMERA_PLLCKDIV_OFF_TIME Configuration of OFF-TIME for
dividing PLL clock (240 MHz) in generation of Camera func-clk:
000h = 1
001h = 2
010h = 3
011h = 4
100h = 5
101h = 6
110h = 7
111h = 8
7-3 NU1 R 0h
2-0 DIVONTIM R/W 0h
CAMERA_PLLCKDIV_ON_TIME Configuration of ON-TIME for
dividing PLL clock (240 MHz) in generation of Camera func-clk:
000h = 1
001h = 2
010h = 3
011h = 4
100h = 5
101h = 6
110h = 7
111h = 8
